TP-Link Omada EAP613 wireless access point 1775 Mbit/s White Power over Ethernet (PoE)

Name: TP-Link Omada EAP613 wireless access point 1775 Mbit/s White Power over Ethernet (PoE)
SKU: EAP613
Availability: InStock

Original price was: $99.99.Current price is: $91.63.

SKU: EAP613

Add to compare

Add to wishlist

Shipping & Delivery

Courier delivery

Our courier will deliver to the specified address

2-3 Days

From $20

DHL Courier delivery

DHL courier will deliver to the specified address

2-3 Days

From $40

Warranty 1 year

More details

Free 30-Day returns

More details

Description

Specifications

Performance
Maximum data transfer rate	1775 Mbit/s
Ethernet LAN data rates	100,1000 Mbit/s
Spread spectrum method	OFDMA
2.4 GHz	Yes
5 GHz	Yes
Frequency band	2.4 – 5 GHz
Wireless isolation	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Automatic channel selection	Yes
Web-based management	Yes
VLAN support	Yes
Reset button	Yes
Rate limiting	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Management platform	Omada
Certification	CE, FCC, RoHS
MIMO type	Multi User MIMO
MIMO	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
Compatible operating systems	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Features
6 GHz	No
Maximum data transfer rate	1775 Mbit/s
Ethernet LAN data rates	100,1000 Mbit/s
Spread spectrum method	OFDMA
2.4 GHz	Yes
5 GHz	Yes
Frequency band	2.4 – 5 GHz
Wireless isolation	Yes
Wi-Fi Multimedia (WMM)/(WME)	Yes
Automatic channel selection	Yes
VLAN support	Yes
Rate limiting	Yes
Networking standards	IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Transmitting power (FCC)	<25 dBm (2.4 GHz); <25 dBm (5 GHz)
Transmitting power (CE)	<20 dBm(2.4 GHz, EIRP); <23 dBm(5 GHz band1/2, EIRP); <25 dBm (5 GHz band3)
Automatic channel scanning	Yes
MIMO type	Multi User MIMO
MIMO	Yes
Band steering	Yes
Airtime Fairness (ATF)	Yes
Maximum data transfer rate (2.4 GHz)	574 Mbit/s
Maximum data transfer rate (5 GHz)	1201 Mbit/s
BeamForming	Yes
Compatible operating systems	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Security
Security algorithms	HTTPS, SNMP, SNMPv2, SNMPv3, WPA, WPA2, WPA3
Number of SSID supported	16
Management features
Web-based management	Yes
Management platform	Omada
Ports & interfaces
USB 2.0 ports quantity	0
Ethernet LAN (RJ-45) ports	1
DC-in jack	Yes
Power
Power consumption (typical)	9.6 W
Power consumption (max)	10.6 W
Input current	1 A
Power over Ethernet (PoE)	Yes
Power over Ethernet (PoE) type supported	Passive PoE
DC voltage range	12 V
Design
Reset button	Yes
Placement	Ceiling, Wall
LED indicators	Yes
Product colour	White
Certification	CE, FCC, RoHS
Antenna
Antenna type	Internal
Antennas quantity	4
Antenna gain level (max)	5 dBi
Certificates
Certification	CE, FCC, RoHS
Software
Automatic channel scanning	Yes
Weight & dimensions
Width	6.3″ (160 mm)
Depth	6.3″ (160 mm)
Height	1.32″ (33.6 mm)
Packaging data
Quick start guide	Yes
Mounting kit	Yes
Packaging content
Quick start guide	Yes
Mounting kit	Yes
Quantity per pack	1 pc(s)
Operational conditions
Operating relative humidity (H-H)	0 – 40%
Operating temperature (T-T)	10 – 90 ?C
Storage temperature (T-T)	-40 – 70 ?C
Storage relative humidity (H-H)	5 – 90%
System requirements
Compatible operating systems	Microsoft Windows XP, Vista, Windows 7, Windows 8, Windows10, Windows11, Linux
Logistics data
Quantity per pack	1 pc(s)
